Customizing UI / Theming
Phase Two ships a unified theme called phasetwo-ui that covers all four Keycloak theme types — login, account, admin, and email — in a single package. It is built with Keycloakify and shadcn/ui and is the default theme on Phase Two hosted instances.
Branding is applied at runtime through realm attributes, so changes take effect immediately without rebuilding or redeploying the theme JAR. The Styles panel in the admin console (under Extensions) provides a UI for most of these settings — the Admin Portal v2 theme tokens described below are not exposed there yet. To access it, ensure the phasetwo-ui theme is selected for the Admin theme in Realm Settings > Themes.
For email branding (logo, footer), set your realm's email theme to phasetwo-ui. This unlocks the Email Branding settings described in the Emails guide.
If you are looking to build a fully custom theme, we recommend using Keycloakify. Phase Two are sponsors of the project.
The Styles panel and all branding features described on this page require the phasetwo-ui theme to be active. Go to Realm Settings > Themes and set:
- Login theme:
phasetwo-ui - Admin theme:
phasetwo-ui - Account theme:
phasetwo-ui - Email theme:
phasetwo-ui
Simple
The simple override of colors and logo can be accessed in the admin UI under Extensions > Styles. The available override values are organized across four tabs.
General tab
- Logo URL: URL of your logo image. This logo appears on login and account pages. It will be constrained to 150×150px. Use an SVG or PNG with an alpha channel so it renders correctly on any background and inside the Admin Portal. To set a separate logo for emails, use the Email tab.
- Favicon URL: URL of your browser tab favicon.
- App Icon URL: URL of the app icon used within the Admin Portal.
The form includes a live image preview so you can confirm your URLs are resolving correctly before saving.
Login tab
Colors control the look of the login, registration, and related authentication pages. All values are hex color codes (e.g. #3b82f6).
Light mode
- Primary color: Used for buttons, links, and the sidebar panel. Default:
#3b82f6. - Secondary color: Used for secondary accents. Default:
#60a5fa. - Background color: Page background color. Default:
#ffffff.
Dark mode
The theme automatically follows the user's operating system dark mode preference. You can supply separate overrides for dark mode; if omitted, the light-mode values are used as fallbacks.
- Primary color (dark)
- Secondary color (dark)
- Background color (dark)
A CSS field is also available on this tab for arbitrary stylesheet overrides, loaded after the theme styles.
Full CSS
The CSS field in the Login tab accepts arbitrary CSS that is loaded after the theme styles. You can use it for targeted overrides without replacing the entire theme.
The phasetwo-ui login theme is built with shadcn/ui and Tailwind CSS v4. The color system uses a set of --p2-login-* CSS variables that the theme bridges to shadcn's semantic tokens. Overriding these variables in your custom CSS is the lightest-weight way to change colors without touching the color picker fields:
:root {
--p2-login-primary-color: #5b9fdd;
--p2-login-secondary-color: #edf5fb;
--p2-login-background-color: #ffffff;
/* Text color rendered on top of the primary color (e.g. button labels) */
--p2-login-primary-foreground-color: #ffffff;
}
/* Optional: separate dark mode overrides */
.dark {
--p2-login-primary-color-dark: #3b82f6;
--p2-login-secondary-color-dark: #1e3a5f;
--p2-login-background-color-dark: #0f0f0f;
}
Phase Two has assembled a few complete custom themes. View them in our Keycloak Themes Repository.
Manually by Realm attributes
All values set through the Styles panel are stored as Realm attributes. You can set them programmatically via the Keycloak Admin REST API or in a realm export JSON. Use the following attribute keys:
General
| Attribute | Description |
|---|---|
_providerConfig.assets.logo.url | Logo URL for login and account pages |
_providerConfig.assets.favicon.url | Browser tab favicon URL |
_providerConfig.assets.appicon.url | App icon URL for the Admin Portal |
Login (light mode)
| Attribute | Default | Description |
|---|---|---|
_providerConfig.assets.login.primaryColor | #3b82f6 | Buttons, links, sidebar |
_providerConfig.assets.login.secondaryColor | #60a5fa | Secondary accents |
_providerConfig.assets.login.backgroundColor | #ffffff | Page background |
_providerConfig.assets.login.primaryForegroundColor | #ffffff | Text on the primary color. Only takes effect through the brand-token path above, as the legacy fallback for theme.v2.primaryForeground — the legacy stylesheet never emitted a variable for it. |
_providerConfig.assets.login.css | — | Arbitrary CSS appended after theme styles |
Login (dark mode overrides)
Omit one and the fallback depends on the kind of color. primaryColor and secondaryColor are brand colors and fall back to their light-mode values, so a custom brand color stays consistent across modes. backgroundColor does not — it falls back to the dark default, because carrying a light background into dark mode would stop dark mode being dark.
| Attribute | Description |
|---|---|
_providerConfig.assets.login.primaryColor-dark | Primary color in dark mode |
_providerConfig.assets.login.secondaryColor-dark | Secondary color in dark mode |
_providerConfig.assets.login.backgroundColor-dark | Background color in dark mode |
_providerConfig.assets.login.primaryForegroundColor-dark | Foreground text in dark mode |
Email branding
See the Emails page for details on email template customization.
| Attribute | Description |
|---|---|
_providerConfig.assets.logo.base64 | Email logo as a base64 data URI (max 1MB, PNG or SVG recommended) |
_providerConfig.assets.email.footer.line1 | First footer line (defaults to realm display name) |
_providerConfig.assets.email.footer.line2 | Second footer line (optional tagline or contact info) |
Brand tokens (login, Admin Portal, and email)
The login theme and the Admin Portal are built on shadcn/ui components that read their colors from CSS variables, and the email templates use the same values inline. All three resolve one shared set of brand tokens, so branding a realm once brands every surface.
Each token is a realm attribute prefixed with _providerConfig.assets.theme.v2. — for example _providerConfig.assets.theme.v2.primary. Every color token takes an optional dark-mode override named dark<Token>, such as _providerConfig.assets.theme.v2.darkBackground.
Color tokens accept a #rgb or #rrggbb hex value — the recommended format — and also bare CSS color keywords such as red, and the rgb(), hsl(), hwb(), lab(), lch(), oklab() and oklch() functions. Contrast is only measured from hex, so if you use a keyword or a color function, set the matching foreground token explicitly rather than relying on auto-contrast. radius accepts a CSS length such as 0, 4px or 0.5rem. A value matching none of these is ignored as if unset.
Base tokens — each has a built-in default:
| Token | Light default | Dark default | Description |
|---|---|---|---|
background | #ffffff | #09090b | Page surface |
foreground | #09090b | #fafafa | Body text |
primary | #3b82f6 | #3b82f6 | Brand color: primary buttons, links, active items |
primaryForeground | #ffffff | #ffffff | Text and icons on primary; auto-contrasts when unset |
secondary | #60a5fa | #1e3a5f | Secondary buttons and accents |
secondaryForeground | #0a0a0a | #fafafa | Text on secondary; auto-contrasts when unset |
muted | #f4f4f5 | #27272a | Recessed surfaces: sidebar, hover states |
mutedForeground | #71717a | #a1a1aa | De-emphasized text, such as helper text |
border | #e4e4e7 | #3f3f46 | Borders |
Derived tokens — no default of their own; set one to override it, or leave it unset and it follows its base token. This is what lets a lone custom primary also move the focus ring:
| Token | Follows when unset |
|---|---|
card | background |
cardForeground | foreground |
accent | muted |
accentForeground | foreground |
input | border |
ring | primary |
Other tokens — radius (a CSS length) and fontFamily (a CSS font stack).
Three behaviors are worth knowing:
- Brand color is mode-independent. Set
primaryorsecondaryand leave the dark override unset, and dark mode inherits your light value rather than reverting to the default. Surface and neutral tokens never inherit, so a lightbackgroundwill not light up dark mode. - Foregrounds auto-contrast.
primaryForegroundandsecondaryForeground, when unset, are computed as a readable near-black or white from their background's relative luminance.foregrounddoes the same frombackground, but only when that value is measurable hex. - Per-surface defaults differ slightly. The Admin Portal's own
primarydefault is#1570c2and itsradiusdefault is0.5rem, against0.625remon the login pages. Those only apply when you leave the token unset.
Each token resolves independently: the theme.v2 attribute if set, otherwise the surface's legacy fallback where one exists, otherwise a derivation, otherwise the built-in default.
Email is the one surface that does not fall back to resolved defaults — only tokens you have explicitly set reach the email templates, because their built-in defaults deliberately differ from the login palette. An unbranded realm's email is unchanged.
See Admin Portal configuration for how the portal applies these at runtime, including how the sidebar derives from them.
Legacy (deprecated)
These Admin Portal keys follow the Tailwind color scale, with the lowest number lightest. They are still read, but only primaryColor700 still affects rendering, as the legacy fallback for primary. secondaryColor900 used to feed a separate cta token for the neutral emphasized button; that token has folded into primary, so a realm which only customized secondaryColor900 should set _providerConfig.assets.theme.v2.primary instead. Set the theme.v2 tokens to customize anything else.
| Attribute | Default | Description |
|---|---|---|
_providerConfig.assets.portal.primaryColor100 | — | Read, but no longer affects rendering |
_providerConfig.assets.portal.primaryColor200 | — | Read, but no longer affects rendering |
_providerConfig.assets.portal.primaryColor400 | — | Read, but no longer affects rendering |
_providerConfig.assets.portal.primaryColor500 | — | Read, but no longer affects rendering |
_providerConfig.assets.portal.primaryColor600 | — | Read, but no longer affects rendering |
_providerConfig.assets.portal.primaryColor700 | — | Fallback for the primary token when v2.primary is unset |
_providerConfig.assets.portal.primaryColor900 | — | Read, but no longer affects rendering |
_providerConfig.assets.portal.secondaryColor800 | — | Read, but no longer affects rendering; the CTA hover shade now derives from cta |
_providerConfig.assets.portal.secondaryColor900 | — | Fallback for the cta token when v2.cta is unset |
Custom CSS
| Attribute | Default | Description |
|---|---|---|
_providerConfig.assets.portal.css | — | Arbitrary CSS for the Admin Portal |
Custom CSS is appended last, after the generated variables, so it overrides both the tokens and the built-in defaults. Target the CSS variables (--primary, --background, --radius, and the .dark block) or standard selectors.
Custom CSS that targeted the old generated utility classes — .bg-primary-700, .text-primary-500, .bg-primary-gradient, and friends — no longer has any effect, because the portal's components now use semantic shadcn/ui classes such as bg-primary and text-muted-foreground. Migrate that CSS to the variables above. Realms that customized primaryColor100 or primaryColor900 will see neutral surfaces after upgrading — their brand color is preserved through primaryColor700 and their CTA button color through secondaryColor900 — so set the matching v2 tokens to restore custom surfaces.
Full customization details can be viewed in the Phase Two Admin Portal Repo.
Custom Themes
If you decide to use a custom theme, you can upload it yourself from the Phase Two Dashboard under Cluster > Config > Resources. See Cluster Resources for the full walkthrough. Custom themes are available to subscribers of dedicated clusters.
Keycloakify
Keycloakify offers two methods for building custom themes:
- CSS Customization: Basic, but ok for simple changes. Learn more in the Keycloakify documentation.
- Custom (React/Angular) Components: Full customization using React or Angular components, allowing for a more robust and custom theme. If you have a theme library or set of components, you would take this route. Learn more in the Keycloakify documentation.
Ultimately what you choose depends on your needs. We have found that CSS customization of Patternfly is very difficult to get right and cover all cases. In many situations, the built in Patternfly components leave much to be desired from a UX perspective. Our friends at Keycloakify are working on a solution to this, but until that's ready we've started out providing a Shadcn starter component theme which can be used.
Shadcn is a component library that provides a set of varied and robust components that can be used to build a custom theme. It leverages Tailwind CSS for styling and Radix UI for components. The starter only handles a couple of pages, but gives a template to start from. Feel free to use it and PR additions to the templates, we would love to see them!
